Brand Name : LTPM China
Model Number : LTEC series
Certification : CE, GMP, SGS, BV
Place of Origin : China
MOQ : 1set
Price : Negotiation
Payment Terms : T/T,L/C,D/P
Supply Ability : 15sets/month
Delivery Time : 25days
Packaging Details : Export Standard Wooden Case
Usage : capsule,tablets,gums,rubber,etc.
Power : 220v 50hz single phase
Transmission : Electronic
capacity : 200000pcs/h
Brand : LeadTop
Line Length : optional
8 Channel Tablets Counting One Head Filling Machine 200000pcs/H
Main Features
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) Accurate measuring to get excellent filling effect.
4) Running in a high automatization and intellectualization,no pollution
5) Suitable for a wide range of granules, such as tablets, capsules, gels, beans, hardwares, candy, etc.
Details
Filling Nozzle
There is photoelectric sensor detect the bottle, bottle is stopped by rail, then fill granules, quantity reachs, filled bottle is conveyed away.
Vibrating Channels
8 vibrating channels works the same time.
Vibrating device
It is power of granules running to filling nozzle.
Machine Induction
Under the driving of the vibration, the pills pass through the regulating valve below the material container, moving forward in order and fall into counting tunnels. When the pill reaches raster holes, the counting photoelectric will produce a pulse signal and counting. The signal is grouped into the left and the right, accumulated and sent to the PLC. When the set quantity is reached, the flashboard will close. At the same time, the bottle to be filled is already in its position. The funnel cylinder board opens, and the counted pills fall into the bottle. Then the tunnel begins another counting, the positioning cylinder opens, and the filled bottle is sent to the next process. A new bottle is placed under the funnel, a new round of counting and filling starts.
Main Technical Data | ||||
Model | LTEC-12 | LTEC-16 | LTEC-24 | LTEC-32 |
Slide wheel | 12 Channels | 16 Channels | 24 Channels | 32 Channels |
Size of Object | Tablet: φ5-12mm Capsule: 00#-5# all kinds of soft capsule | |||
Size of bottles | 20-300ml | |||
The diameter for bottles mouth | 20-80mm | |||
Output | 4,000pcs/min | 6,000pcs/min | 8,000pcs/min | 10,000pcs/min |
Capacity | 40bottles/min | 60bottles/min | 80bottle/min | 100bottles/min |
Power | 0.9KW | 0.9KW | 1.35KW | 1.35KW |
Power supply | 220V 60HZ | |||
Air pressure | 6kgs/c | |||
Overall dimensions(mm) | 1700×1700×1900 | 2000×1700×1900 | 2800×1700×1900 | 3200×1700×1900 |
![]() |
